FrostFlex FXC Series –18 °C Cold Storage Units | Industrial Freezers

€24.000,00

High-Efficiency Industrial Cold Rooms for Poultry, Doner & Meat Storage

💠 Product Description

The FrostFlex FXC Series represents the new generation of industrial cold storage systems engineered for stable –18 °C operation.
Each unit is designed and assembled in Türkiye using EU-certified components, following IFC and HACCP food safety standards.

Built for poultry, meat, and shawarma production facilities, the FXC Series ensures long-term reliability, energy efficiency, and seamless temperature control — all managed by a smart PLC-based system with remote monitoring.

⚙️ Key Technical Specifications

Model	Compressor Power	Panel Thickness	Temperature Range	Refrigerant	Control System	Cooling Type	Price (€)
FXC-075	5 HP Frescold	120 mm	–15 °C ~ –20 °C	R404A	PLC + HMI	Single Stage	24,000
FXC-100	7.5 HP Dorin	120 mm	–15 °C ~ –20 °C	R404A	PLC + HMI	Single Stage	32,000
FXC-200	15 HP Dorin	120 mm	–15 °C ~ –20 °C	R449A	PLC + HMI	Single Stage	41,000
FXC-300	22 HP Dorin	120 mm	–15 °C ~ –20 °C	R404A	PLC + HMI	Single Stage	46,000
FXC-650	45 HP Dorin	120 mm	–15 °C ~ –20 °C	R452A	PLC + HMI	Single Stage	76,000

🔩 Core Features

Single-stage low-temperature compressor system (optimized for –18 °C)
120 mm polyurethane insulation panels (modular assembly system)
PLC + HMI touchscreen control for real-time monitoring
Stepper Electronic Expansion Valve (EEV) for precise superheat control
PID-based fan speed regulation – energy-efficient condenser operation
Automatic defrost & pump-down system
Ethernet connectivity & remote access with alarm notifications
Optional daily energy analyzer and data logging system
CE & HACCP certified design, compliant with EU food safety standards
Built in Türkiye, powered by Frigor Soğutma / Dorin / Frescold technologies

🧱 Construction & Components

Wall / Ceiling Panels: 120 mm thick PIR sandwich panels
Evaporator: Ceiling or floor-mounted type (customizable)
Condensing Unit: Air-cooled system with energy-optimized fan motors (Ziehl Abegg or EBM Papst)
Refrigerant Options: R404A / R449A / R452A
Voltage: 380 V – 50 Hz (optional 460 V – 60 Hz)
Defrost: Electric or hot gas defrost cycle (automatic)
Drainage: Stainless-steel bottom floor with insulation protection

🧠 Smart Control System

Every FXC unit is powered by a PLC-based intelligent control that manages compressor stages, fan speed, and EEV modulation automatically.

Features include:

Smart temperature management (±0.5 °C precision)
Remote monitoring via Ethernet / Static IP
Alarm email notification for critical events
Integrated energy-saving algorithm
Optional cloud-based data recording

🚚 Shipping & Installation

Manufactured and shipped from Istanbul, Türkiye
Export packaging with foam protection + wooden crate
Optional on-site installation & commissioning
EXW / CIF delivery options available
Estimated production time: 4–6 weeks

🌍 Applications

Poultry & Meat Processing Plants
Doner & Shawarma Production Facilities
Hotel & Restaurant Cold Rooms
Frozen Food Distribution Warehouses
Industrial Food Storage Lines
